D300 Mobile Fume Extraction Unit
The HiVent D300 mobile welding fume extraction unit is a professional product with a fully automatic, cleanable cartridge filter. It can be used in MMA, MIG/MAG, and TIG welding processes, as well as grinding operations.
Innovative Design
The D300 was designed in a compact structure for use in heavy-duty conditions.
The cartridge filter with fully automatic cleaning system provides significant savings in operating costs.
The D300 design offers user and service-friendly operation.
To prevent coarse particles and sparks from reaching the filter directly, a drawer type washable metal mesh filter is available.
Operating hour meter, filter full warning and fault warning are standard.
It provides low noise level thanks to its special clean air outlet design.
Technical Data
656.53.3300
Motor power: 1,5 kW
Voltage: 230 V AC / 50 Hz (single-phase)
Max. airflow: 3.500 m³/h
Working airflow: ~ 1300 m³/h (in the hood)
Fan speed: 2810 rpm
Sound pressure: 68 dBA (EN ISO 3476)
Dimensions (W×L×H): 650 × 1260 × 1150 mm
Weight: 138 kg
Suction arm: Single arm, 3 m (2 m or 4 m optional)
Metal mesh filter: washable, ISO Coarse – ISO 16890 (G2)
Main filter: Nanofibre-coated cartridge ×1, ePM1 85% – ISO 16890 (F9)
Filter area: 21 m²
Filter cleaning: Automatic jet-pulse
